Easy Setup

To setup your BEASTX system there is no need for any additional devices. All you need is your radio system and your helicopter. Thanks to the well proven EasySetup system you can do all the necessary adjustment directly at the device and in very short time.

In combination with a Spektrum® or JETI® telemetry radio system, you can follow the setup process through the display of your remote control.

For additional features you can use the StudioX app for PC/Mac/Smartphone/Tablet in combination with the USB2SYS or BLE2SYS interface (optional available). These apps allow to setup your device, save/restore paramaters, download firmware updates, load preset heli configurations and make advanced adjustments to fully customize your BEASTX device.







Radio systems

Our devices support nearly all types of radio systems with conventional receiver wiring as well as lots of different serial signal receivers:

  • FUTABA® SBUS
  • JR® XBUS
  • Jeti® EXBUS & UDI
  • ALIGN®/FlySky® iBus
  • Spektrum® SRXL & SRXL2
  • FRSky® F.Port & S.Port
  • Serial PPM
  • HOTT SUMD
  • TBS CRSF (OpenTX, EdgeTX and ELRS radios)
BEASTX Logo

Also you can connect Spektrum®/JR®/ALIGN® remote satellites directly to our devices. (Please note some protocols aren't available on all devices; see device specific instructions!)







Heli types

Preset swash plate mixing for mCCPM and 90, 120 and 140 degrees eCCPM. You can fully customize the swash mixing with up to 4 swash plate servos and virtual phasing, i.e. for scale helicopters. Swash plate servo update rate with up to 400Hz (Not on all devices, please see device specific instructions!)
BEASTX Logo



Gyro stabilization

BEASTX Logo
Integrated tail gyro with torque precompensation ("RevoMix") supports all types of rudder servos with 760, 960 and 1500/1520µs pulse width and up to 600Hz update rate (Not on all devices, please see device specific instructions!).



Integrated motor governor

In combination with a speed sensor pickup or ESC with motor speed signal output MICROBEAST PLUS HD / MICROBEAST ULTRA can take over control of the motor speed of your heli's main rotor. Additionaly you can monitor the motor speed when using a telemetry radio. The governor is available for electric and nitro/gas driven helicopters.
BEASTX Logo



Tail motor support

BEASTX Logo
Your heli has a tail motor instead of conventional tail drive with servo control? No problem! With BEASTX we also support these types of heli.







Additional features

All BEASTX systems are equipped with the basic flybarless stabilization and some additional functions that are mandatory to fly your helicopter. The systems can be upgraded with additional features by paid upgrade function. The upgrades can be flashed on your device using the optional StudioX app and BLE2SYS/USB2SYS interface.

AttitudeControl

AttitudeControl will add recue bailout and constant leveling to your device. This can make flying a RC helicopter even more fun. When coming from RC drones you may find flying a helicopter quite easy with help of AttitudeControl.

Bank Switching

Bank Switching allows to change between different parameter sets in flight to serve different flight conditions or flying styles for professional pilots.

Telemetry hub

The telemetry hub transforms your BEASTX device into a control center for processing incoming and outgoing telemetry data. It supports common ESC protocols (Kontronik®, YGE®, Scorpion®, Hobbywing®, Spektrum® AVIAN) and radio systems (Jeti® EXBUS, Spektrum® SRXL2, Graupner® HOTT, CRSF, FrSky® S.Port, Futaba® SBUS2 (MB ULTRA), FrSky® F.Port (MB ULTRA)).

ProEdition

The ProEdition upgrade unlocks all features at once at a fair pricing, plus you will get free upgrades also in future - guaranteed!
